Fiber 980nm
Diode Fiber Laser is a 980nm transdermal diode, with optical fiber transmission system. This cutting-edge technology has been designed to treat vascular lesions and diseases up to 4 mm diameter. Its advanced designed, such as its small and portable size, make it a great option for every clinic.
– It boasts an excellent transdermal penetration, which reduce side effects like erythema, or pigmentations disorders. No allergic reactions to be produced, neither needles are needed.
– Thanks to the low absorption by melanin of 980nm wavelength, the Diovas treatment can be performed in every skin type and during the whole year. In addition, patients can return to normal activity immediately after treatment..
| Laser type | Fiber Diode |
| Wavelength | 980 nm |
| Laser Source power | 30 w |
| Equipment power | 100 w |
| Screen size | LCD 8.6″ Color |
| Software | English and Others |
| Pulse width | 5 ms – 100 ms |
| Guide light | Diode 650nm |
| Spot size / handle | 1,4 -1,9 – 2,4 mm |
| Working Mode | Continuous / Pulse |
| Shot frequency | 1 Hz – 20 Hz |
| Cooling system | Air Cooling system |
| Power voltage | 220 V / 110 V |
| Equipment size/Weight | 40cm x 33cm x 20cm / 6kg7 cm x 60 cm x 42 cm / 40kg |
| Export pack size/Weight | 53 cm x 45 cm x 42 cm / 18k |
Pulse mode: Telangectasias, varicose veins, cuperosis, rosacea, ruby spots, hemangioma, venous lakes.
Continuous mode: Filiform warts, Condylomas, Acrochordons
Telangiectasias – 3 sessions
Rubies spots – 2 sessions
